Electrical Wire UL1330 FEP Teflon High Temperature Tinned Copper Insulated Wire200c Orange
Overview Product Description Electrical wire UL1330 FEP Teflon high temperature tinned copper insulated wire200C orange
Overview
Detailed PhotosCompany pictures
Basic Info.
Model NO. | UL1330 |
Material Shape | Round Wire |
Range of Application | Heat Resistant |
Certification | ISO9001, CCC, RoHS |
Brand | Werlg |
Feature | High Temperature Resistance, Cut Resistance |
Colour | Red, Blue, Green, Brown, Yellow, White, Black |
Company Type | Manufacturer |
Use for | Household Appliance |
Temperature | 200 Centidegree |
Voltage | 600V |
Size | AWG 30 |
UL Certificate | UL1330 |
Transport Package | PE and Carton |
Specification | ROHS, UL |
Trademark | WERLG |
Origin | Zhejiang China |
HS Code | 8544492100 |
Production Capacity | 200000meters/Day |
Product Description
Product DescriptionElectrical wire UL1330 FEP Teflon high temperature tinned copper insulated wire200C orange
TECHNICAL DATANominal Voltage:600VTemperature Range:-100ºC~+200ºC/150ºCConductor:Tinned CopperInsulator:FEP TEFLONO.D.Tolerance:±0.03mmTesting Volta:2500VColour: white, blue, red, black, brown, orange, purple, gray, yellow, green, transparent, yellow-green, etcCHARACTERISTICHigh temperature resistance, low temperature resistance, anti-acid, anti-oil, antisepsis and moistureproof, UL 758, RoHs compliance.APPLICATIONApply to household appliance, illumination & lighting & headlamp, electric machines, temperature sensor, military series, metallurgy chemical series, motor cars & ships electrical installation.
UL1330 | Conductor | OverDiamter±0.03mm | Insulator | Technical Data | Packing(m/roll) | ||||
Size | ConductorConstructionNo./mm | Diametermm | Material | AverageThicknessmm | Colour | Temperature Range(ºC) | Nominal voltage | ||
30 AWG | 7/0.1 | 0.3 | 1.32 | FEP teflon | 0.507 | red,yellow,blue,green,black,white,purple,brown,orange,yellow-green,transparent | "-100ºC~+200ºC/150ºC | 600V | 610 |
1/0.254 | 1.27 | FEP teflon | 0.488 | 610 | |||||
28 AWG | 7/0.12 | 0.36 | 1.38 | FEP teflon | 0.507 | 610 | |||
1/0.32 | 1.34 | FEP teflon | 0.485 | 610 | |||||
26 AWG | 7/0.16 | 0.48 | 1.5 | FEP teflon | 0.506 | 610 | |||
1/0.4 | 1.42 | FEP teflon | 0.479 | 610 | |||||
24 AWG | 7/0.2 | 0.6 | 1.62 | FEP teflon | 0.504 | 610 | |||
19/0.12 | 0.6 | 1.62 | FEP teflon | 0.508 | 610 | ||||
22 AWG | 7/0.254 | 0.76 | 1.78 | FEP teflon | 0.502 | 610 | |||
19/0.16 | 0.75 | 1.77 | FEP teflon | 0.482 | 610 | ||||
20 AWG | 7/0.32 | 0.96 | 1.97 | FEP teflon | 0.496 | 610 | |||
19/0.19 | 0.95 | 1.97 | FEP teflon | 0.507 | 610 | ||||
18 AWG | 7/0.4 | 1.2 | 2.2 | FEP teflon | 0.489 | 610 | |||
19/0.235 | 1.18 | 2.2 | FEP teflon | 0.508 | 610 | ||||
16 AWG | 7/0.5 | 1.5 | 2.52 | FEP teflon | 0.496 | 305 | |||
19/0.3 | 1.5 | 2.52 | FEP teflon | 0.505 | 305 | ||||
14 AWG | 19/0.37 | 1.85 | 2.87 | FEP teflon | 0.504 | 305 | |||
12 AWG | 19/0.48 | 2.4 | 3.42 | FEP teflon | 0.502 | 305 | |||
10 AWG | 37/0.43 | 3.01 | 4.03 | FEP teflon | 0.504 | 305 | |||
8 AWG | 37/0.54 | 3.78 | 5.3 | FEP teflon | 0.753 | 305 | |||
6 AWG | 133/0.355 | 4.79 | 6.3 | FEP teflon | 0.786 | 305 | |||
2 AWG | 133/0.56 | 7.37 | 8.9 | FEP teflon | 0.72 | 305 |
