Shenguan Wire Cable PVC Insulation Multi Core Electric Shielded Signal Control Wire Nsgafou 3 Kv Shd
Basic Info.
| Wire Core Material | Red Copper Wire |
| Certification | ISO, CCC, CE, RoHS, VDE |
| Model | AGRP |
| Other Core | 1 Core, 2 Core, 3 Core, 4 Core, 5 Core |
| MOQ | 10000m |
| Sample | Contact to Get Free Sample |
| Delivery Time | 7 Days |
| Transport Package | Wood Box |
| Specification | (L)725*(W)600*(H)1105mm |
| Trademark | SHENGUAN |
| Origin | Shenyang, China |
| Production Capacity | 5000000PCS/Month |
Product Description
TOP TEN CABLE MANUFACTURER/EXPORTER IN CHINAANNUAL EXPORT VOLUME EXCEED 200MILLION USDWITH UL,TUV,KEMA,CE,BV,PSB,SABS,LLOYD'S,GL,NK,KR,ABS PRODUCTS CERTIFICATIONSWITH TUV TYPE TESTING REPORTWIDE PRODUCTS RANGEISO9001,ISO18001,OHSAS18001 SYSTEM CERTIFICATIONSCNAS APPROVAL LABROTARY
Type and name:
Type | Designation | Applications |
YJV | Copper conductor,XLPE insulated,PVC sheathed power cable | For laying indoors,in tunnel or cable trench,unable to bear external mechanical forces.Single core cable is not allowed to laid in magnetic duct. |
YJLV | Aluminum conductor,XLPE insulated,PVC sheathed power cable | |
YJY | Copper conductor, XLPE insulated,PE sheathed power cable | |
YJLY | Aluminum conductor, XLPE insulated,PE sheathed power cable | |
YJV22 | Copper conductor,XLPE insulated,steel tape armoured,PVC sheathed power cable | For laying indoors,in tunnel in cable trench,or direct in ground,able to bear external mechanical forces.Single core cable is not allowed to laid in magnetic duct. |
YJLV22 | Aluminum conductor,XLPE insulated,steel tape armoured,PVC sheathed power cable | |
YJV23 | Copper conductor,XLPE insulated,steel tape armoured,PE sheathed power cable | |
YJLV23 | Aluminum conductor,XLPE insulated,steel tape armoured,PE sheathed power cable | |
YJV32 | Copper conductor,XLPE insulated,steel wire armoured,PVC sheathed power cable | For laying indoors,in tunnel cable trench,well or direct in ground,able to bear external mechanical forces and certain pulling force. |
YJLV32 | Aluminum conductor,XLPE insulated,steel wire armoured,PVC sheathed power cable | |
YJV33 | Copper conductor,XLPE insulated,steel wire armoured,PE sheathed power cable | |
YJLV33 | Aluminum conductor,XLPE insulated,steel wire armoured,PE sheathed power cable |
| 2×1 | 0.6 | 0.8 | 5. 9 or 3. 9×6. 2 | 7. 5 or 4. 7×7. 5 | 0.01 |
| 2×1. 5 | 0.7 | 0.8 | 6.8 | 8.6 | 0.01 |
| 2×2. 5 | 0.8 | 1 | 8.1 | 10.6 | 0.009 |
| 3×0. 75 | 0.6 | 0.8 | 6 | 7.6 | 0. on |
| 3×1 | 0.6 | 0.8 | 6.3 | 8 | 0.01 |
| 3×1. 5 | 0.7 | 0.9 | 7.4 | 9. I | 0.01 |
| 3×2. 5 | 0.8 | 1.1 | 9.2 | 11.4 | 0.009 |
| 4×0. 75 | 0.6 | 0.8 | 6.6 | 8.3 | 0.011 |
| 4×1 | 0.6 | 0.9 | 7.1 | 9 | 0.01 |
| 4×1. 5 | 0.7 | 1 | 8.4 | 10.5 | 0.01 |
| 4×2. 5 | 0.8 | 1.1 | 10.1 | 12.5 | 0.009 |
| 5×0. 75 | 0.6 | 0.9 | 7.4 | 9.3 | 0.011 |
| 5×1 | 0.6 | 0.9 | 7.8 | 9.8 | 0.01 |
| 5×1. 5 | 0.7 | 1.1 | 9.3 | 11.6 | 0.01 |
| 5×2. 5 | 0.8 | 1.2 | 11.2 | 13.9 | 0.009 |
A:Of course, we can send samples to all parts of the world, our samples are free, but customers need to bear the courier costs. Q:What product information do I need to provide?
A:You need to provide the grade, width, thickness, coating and the number of tons you need to purchase. Q:What are the shipping ports?
A:Under normal circumstances, we ship from shengyang, Ningbo ports, you can choose other ports according to your needs. Q:About product prices?
A:Prices vary from period to period due to cyclical changes in the price of raw materials. Q:What are the certifications for your products?
A:We have ISO 9001, SGS, EWC and other certifications. Q:How long does your delivery time take?
A:In general, our delivery time is within 7-30days, and may be delayed if the demand is extremely large or special circumstances occur. Q:Can I go to your factory to visit?
A:Of course, we welcome customers from all over the world to visit our factory. However, some of the plants are not open to the public. Q:Does the product have quality inspection before loading?
A:Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed. Q:How to pack the products?
A:The inner layer has a waterproof paper outer layer with iron packaging and is fixed with a fumigation wooden pallet. It can effectively protect products from corrosion during ocean transportation. Q:What is your working time?
A:In general, our online service time is Beijing time: 8:00-22:00, after 22:00, we will reply to your inquiry during the next working day.
